| Spécifications |
|---|
| Type de produit | Lecteur réseau |
| Entrées | 1x RJ45 Ethernet 10/100/1000 BASE-T 1x Optique Toslink 1x Coaxial 1x Entrée ligne RCA stéréo 1x USB-B 1x HDMI eARC 3x USB-A (USB Host) |
| Sorties | 1x Optique Toslink 1x Coaxial 1x Sortie Pre-Out RCA 1x HDMI 2.0 (jusqu'à 3840*2160px 60Hz) |
| Connectivité sans-fil | WiFi 802.11ac Dual Band Bluetooth 4.2 |
| OS | Android 7.1 custom |
| Écran tactile | LCD TFT 12.6" |
| CPU | Cortex-A72 Dual-Core 1.8GHz Quad-Core Cortex-A53 1.4GHz |
| GPU | Mali-T864, OpenGL ES1.1/2.0/3.0/3.1, OpenVG1.1, OpenCL, DX11 |
| RAM | 4GB LPDDR4 |
| DAC | ESS ES9038Pro |
| Services de streaming supportés | TIDAL Qobuz Apple Music Bugs ROSE Tube Webradios ROSE Podcast |
| Protocoles WiFi supportés | AirPlay DLNA Roon Ready Spotify Connect |
| Systèmes de fichiers supportés pour périphériques de stockage (USB Host) | NTFS exFAT FAT32 |
| Protocoles réseau de transfert de fichiers supportés | SMBv1 FTP Webdav |
| Taux d'échantillonnages supportés | PCM jusqu'à 32bit 768kHz DSD Natif jusqu'au DSD512 |
| Codecs audio supportés | MQA, WAV, FLAC, AIFF, WMA, MP3, OGG, APE, DFF, DSF, AAC, CDA, AMR, APE, EC3, E-EC3, MID, MPL, MP2, MPC, MPGA, M4A, ALAC, PCM |
| Codecs vidéo supportés | ASF, AVI, MKV, MP4, WMV, MPEEG-1, MPEG-2, MPEG-4, H.263, H.264, H.265, VC-1, VP9, VP8, MVC, H.264/AVC, Bas |
| Application de contrôle | ROSE Connect (Android, iOS, PC) |
| Puissance | 2x 250W |
| Sensibilité | Entrée ligne : 2Vrms Sortie Pre-Out : 2Vrms |
| Réponse en fréquence | 10Hz ~ 83kHz (+1/-3dB) |
| THD+N | Sortie Pre-Out : 0.00033% @ 1kHz, 600Ω, 2Vrms Sortie HP : 0.007% @ 50W, 8Ω / 0.01% @ 100W, 8Ω / 0.1% @ 250W, 8Ω |
| Impédance d'entrée | 100kΩ |
| Impédance de sortie | 50mΩ |
| SNR | Sortie Pre-Out : 124dB @ 1kHz, 600Ω, 2Vrms Sortie HP : 109dB @ 1kHz, 8Ω, 250W |
