MONACOR SPH-176 Speaker Driver Midbass 70W 8 Ohm 90dB

Monacor SPH-176
No customer reviews yet, login to write a review.

By buying this product you get 6 loyalty points

Reference : 840
New product

63,90 €tax incl.

53,25 € tax excl.
Including 0,30 € for green tax

- +

Shipping date: 18-04-2024.

Orders placed before 12h (GMT+1) will generally be shipped the same day (working day).

Livraions depuis la france
Livraison depuis la france Livraison depuis la france Livraison depuis la france

Shipping from France
Billing in France
Technical support in France

Produit garantie 2 ans
More info
SPH-176: this high-quality speaker, made in Germany, meets all the requirements of a modern hi-fi bass-loudspeaker for a particularly attractive price; focus on the perfect centering of the coil, large linear travel, suspension with a profile rectifying frequency band and exceptional Thiele and Small parameters for bass.

High-quality Hi-Fi bass-speaker, 120 W MAX , 8 Ω

This bass-midrange speaker with a paper membrane with a good pulse, a rubber suspension, optimized properties in the bass, makes it possible to produce deep bass speakers and a high degree of leveling. This speaker can be used as a 2-way Hi-Fi speaker, in dual loudspeaker systems and even very small subwoofers.

Klang + Ton 6/03

"The SPH-176 is almost the ideal image of a conventional bass-midrange speaker."


"The Number One SPH-176 is a classic speaker with featuresmodernists who are interested in it. A successful combination. "

+ very linear frequency response

+ many successful solutions

+ large linear excursion

+ very good price

 Impedance (Z) 8 Ω
 Resonance frequency (fs) 39 Hz
 Maximum bandwidth f3-4500 Hz
 Maximum power 120 W MAX
 Rated power (P) 70 W RMS
 Average sound pressure (1 W / 1 m) 90 dB
 Compliance susp. (Cms) 1.01 mm / N
  Moving mass (Mms)  14 g
 Mechanical overvoltage. (Qms) 2.27
 Electrical overvoltage (Qes) 0.44
 Fact. total surge (Qts) 0.37
 Volume equ. (VAS) 27 l
 DC resistance. (Re) 6.6 Ω
 Force factor (BxL) 7.7 Tm
 Inductance coil (The) 0.75 mH
 Coil diameter 25 mm
 Coil holder Alu
 Linear Excursion (X MAX ) ± 5.5 mm
 Transmitting surface (Sd) 140 cm 2
 Magnet Weight 16 oz.
 Weight 1.25 kg


Data sheet
Speaker Power (W RMS)70.0
Speaker TypeMidbass
Impedance (Ω)8
Loudspeaker diameter (mm)176.0
Diaphragm typePaper
Efficiency / Sensitivity (dB)90.0
Max Linear Excursion (Xmax) (mm)5.5
Lowest frequency (Hz)N/A
Highest frequency (Hz)4500
