The "MAJESTIC" cable from the 1877 PHONO brand allows you to connect your 5-pin connector to a Phono preamplifier with RCA * jacks.
Resolutely Audiophile in its design, it is especially useful for connecting old record players to our modern equipment, leaving them an additional chance to amaze us by their inimitable analog sound.
Mthe MAJESTIC is distinguished by the use of 4 monocrystalline OCC copper conductors with an individual diameter of 0.40mm, insulated with a Dupont Teflon®-FEP thermoplastic film.
lass = "lineText"> This second material, of French design, is renowned throughout the world for its excellent chemical resistance, its exceptional electrical properties and its incredible thermal resistance (-240 to + 205 ° C). In addition, Teflon® FEP is a proven flame retardant product, which earned it an ASTM D-3418 certification.
neText ">This first insulation is backed up by a spiral-coated copper screen that is enclosed in an Aluminum / Mylar strip to improve the immunity of conductors against radio interference (RFI) and electromagnetic interference (EMI).
Life2 individual PVC sheaths to reinforce the "physical" protection of the conductors while ensuring flexibility and flexibility in thea double layer of antistatic PET (Polyethylene Terephthalate ).
The black PVC outer sheath provides greater resistance to the harshness of the outside world. It is covered with a superb black and blood nylon sheath which, with the solid beech partition box, gives the MAJESTIC an inimitable cachet.
Thees Connectors also show the manufacturer's zeal, and its propensity to always use what's best: Thus the 5-pin DIN plug consists of non-magnetic copper plated with 24k fine gold and insulated Teflon , excuse the bit ...
The RsCA are not to be outdone and also benefit from a 24k Gold coating and Teflon insulation. Finally, it should be noted that each bond is made using a solder containing 5% of silver. *NOTE :
This cable does not allow to connect a turntable to a conventional line input (CD, TAPE, AUX ...). In order to operate, it requires an input on RCA sockets of higher sensitivity, generally accompanied by a grounding, and leading to a correction filter conforming to the RIAA standard. This type of input is generally labeled "PHONO" or "TURNTABLE" on integrated preamplifiers and amplifiers.
- Number of Drivers:4
- <strong> Composition of Conductors: Copper OCC of Section 0.40mm²
- Input: DIN plug 11.75mm 5 pins Copper Plated 24k Gold & Insulated Teflon
- Output: 2 RCA Plugs + 24k Gold Plated Ground & Isolated Teflon
- Shielding: Braided Copper Sheath, Aluminum / Mylar Sheath, PET Insulation Sheath ( Polyethylene Terephthalate )
- Total Cable Length: 1.20m
- Finish: Black & Red Nylon Sheath
