CLARITYCAP ESA Capacitor 250V 8.2μF

ClarityCap Condensateurs ESA 250VDC 8.2µf
The performance of ESA capacitors has been significantly improved by reducing the effects of sound resonance from the capacitor winding. This is achieved by a careful selection of the quality of the Polypropylene base film, combined with pure Aluminium metallisation and a high level of control over the production process.
No customer reviews yet, login to write a review.

By buying this product you get 1 loyalty point


Reference : 7493
New product

10,50 €tax incl.

8,75 € tax excl.
This product is discontinued
Livraions depuis la france
Livraison depuis la france Livraison depuis la france Livraison depuis la france

Shipping from France
Billing in France
Technical support in France

Produit garantie 2 ans

More info

ClarityCap ESA

Capacitor 250V 8.2µF

ClarityCap ESA Capacitor 250V 120µF

The ESA range is the result of a 2-year research programme conducted between ClarityCap and the renowned Acoustic Research Centre at the University of Salford.

The performance of ESA capacitors has been significantly improved by reducing the effects of sound resonance from the capacitor winding. This is achieved by a careful selection of the quality of the Polypropylene base film, combined with pure Aluminium metallisation and a high level of control over the production process.

The ESA range offers exceptional performance in audio applications in both 250VDC and 630VDC. A guaranteed 3% tolerance ensures consistency between filter components for a balanced system.

ClarityCap ESA Condensateur

Technical characteristics

Specifications
Product typeCapacitor
Capacity8.2µF
Voltage250V
Tolerance3%
Dissipation factor0.001 @ 1kHz & 20±3°C
Insulation resistance10MΩ-µF @ rated voltage & 20±3°C
Dielectric absorption0.1% @ 20±3°C
Temperature range-40°C to +70°C
Wires materialOFC Copper
Wires sheathPVC
General
DimensionsØ33 x 31mm
Wires diameter1mm

Data sheet
Tolerance (%)3.0
Capacitor capacitance8.2
Rated voltage (V)250.0
Capacitor typeFilm capacitor
Capacitor formatAxial
