TOPPING E30 II DAC 2x AK4493S XMOS XU208 32bit 768kHz DSD512 Silver
By buying this product you get 14 loyalty points
![[GRADE B] FIIO K9 PRO ESS DAC 2x ES9038PRO Headphone Amplifier 2x THX-AAA 788+ Bluetooth aptX-HD LDAC 32bit 384kHz DSD256 MQA](https://www.audiophonics.fr/60594-thumb_default/fiio-k9-pro-ess-dac-2x-es9038pro-headphone-amplifier-2x-thx-aaa-788-bluetooth-aptx-hd-ldac-32bit-384khz-dsd256-mqa.jpg)
Topping E30 II
DAC 2x AK4493S XMOS XU208 32bit 768kHz DDD512 Silver
Topping comes back with the compact DAC E30 II, a real evolution of the excellent E30, presenting many technical improvements allowing to reach even better sound performances. Dual DAC AK4493S, USB XMOS XU208 interface, optimized power supply, the newcomer from Topping will allow you to enjoy an excellent DAC at a very affordable price.
Differences between the E30 II and the E30
E30 II
E30
DAC
2x AK4493S
1x AK4493
DIR
Digital processing : more stable and better compatibility
CS8416
SINAD
119dB
115dB
SNR
123dB
120dB
Dynamic range
123dB
119dB
Noise
< 1.5µV
< 2.0µV
Internal power supply
Discrete LNRD : stronger noise suppression capabilité, better stability
LDO
Dual AKM AK4493S DAC
The main improvement of the E30 II is its digital/analog conversion stage. It now uses two AKM AK4493S DAC chips connected in parallel, each dedicated to a channel, thus offering much better performance. These chips are themselves improvements of the AK4493 chip. They also benefit from the proprietary Velvet Sound technology and ensure a sound reproduction that is both precise and rich in detail.
XMOS XU208 USB Interface
The USB-B input of the E30 II allows a simple and powerful use of the DAC. It is associated with an XMOS XU208 interface and a particularly stable and reliable Thesycon custom driver. Moreover, this input ensures an extremely low jitter level. The combination of this interface with the AK4493S DACs also allows the E30 II to support high resolution audio streams, up to PCM 32bit 768kHz and DSD512.
Simple and efficient connectivity
In terms of connectivity, the E30 II does not overdo it but offers a complete range of connectivity, allowing it to be integrated without difficulty into the vast majority of audio systems. The input is USB-B, Toslink optical and coaxial. The output is simply in stereo RCA.
| 1 | LED screen |
| 2 | IR receiver |
| 3 | Multifunction touch button |
| 4 | Right channel RCA output |
| 5 | Left channel RCA output |
| 6 | Coaxial input |
| 7 | Optical Toslink input |
| 8 | USB-B input |
| 9 | Jack DC power connector (5VDC 1A) |
5V Power supply
Practical, the E30 II is powered by 5VDC. It can be used almost anywhere and can be connected to a computer, a phone charger or a powerbank. The integrated protection circuitry protects the E30 II and will display an error message in case of a bad power supply.
Discrete LNRD circuit
In order to solve the noise problem that can be caused by the 5V power supply, the E30 II includes a discrete LNRD (Low Noise Reference Driver) circuit. It filters the noise from the 5V power supply to provide an ultra-low noise and stable electrical signal to the audio circuits. Thus, the background noise of the E30 II is less than 1.5µV.
PCM & DSD Filters
The E30 II provides six PCM filters and two DSD filters. These allow you to adjust the sound reproduction of the device according to your preferences and your audio system.
Auto ON/OFF function
Avec sa fonction Auto ON/OFF, le E30 II s'allume et sélectionne automatiquement l'entrée recevant un signal audio valide. de la même manière, si l'appareil ne reçoit aucun signal durant une minute, celui-ci s'éteint alors automatiquement.
Pure DAC Mode
The E30 II has a function to lock its maximum output level. This allows it to operate in pure DAC mode. In this mode, the DSD signals bypass the DATT soft mute and the Delta Sigma modulator to provide optimal sonic performance.
Volume control
Topping's DAC also includes a volume control, allowing the volume to be adjusted over a range of -99dB to 0dB using the remote control. The E30 II can therefore be directly connected to a power amplifier or active speakers.
Technical characteristics
| Specifications | |
|---|---|
| Product type | DAC |
| DAC Chip | 2x AKM AK4493S |
| Înputs | 1x USB-B 1x Optical Toslink 1x Coaxial |
| Output | 1x Stereo RCA |
| Supported sampling rates | USB : PCM up to 32bit 768kHz, Native DSD up to DSD512, DSD DoP up to DSD256 Coaxial / Optical : PCM up to 24bit 192kHz |
| THD+N @ 1kHz, A-Weighting | < 0.00015% |
| THD @ 90kBw, No-Weighting | < 0.0006% @ 20Hz-20kHz |
| SNR @ A-Weighting | 123dB @ 1kHz |
| Dynamic range @ A-Weighting | 123dB @ 1kHz |
| Frequency response | 20Hz-20kHz (±0.3dB) 20Hz-40kHz (±0.8dB) |
| Output level | 2.1Vrms @ 0dBFS |
| Noise @ A-Weighting | < 1.5µVrms |
| Crosstalk @ 1kHz | -132dB |
| Channel balance | < 0.3dB |
| Output impedance | 20Ω |
| General | |
|---|---|
| Dimensions | 100 x 125 x 32mm |
| Color | Silver |
| Package | 1x Topping E30 II 1x Remote cotnrol 1x Male USB-A to male USB-B cable 1x Male USB-A to Jack DC cable |
| Input | USB |
| Input | Optical |
| Input | SPDIF |
| Output | RCA |
| DAC / ADC Chip | AK4493S |
| Max sampling rate | 768kHz |
| Max sampling rate | DSD512 |
| Color | Silver |
| Networking | No |
| Remote Control | Yes |
