Shanling offers with the M1S a technical and aesthetic evolution of the M1 high fidelity digital player. This S version benefits from an improved digital/analog conversion stage now based on an ESS ES9038Q2M chip as well as an updated Bluetooth receiver in version 5.0. Its appearance is also modernized while keeping its incredible compactness, a real distinctive element of the M1. Thus, the M1S is the ideal companion to accompany you both on the move and at home to offer you listening sessions of incredible quality.

No customer reviews yet, login to write a review.

By buying this product you get 22 loyalty points


Reference : 17723
New product

229,00 €tax incl.

190,83 € tax excl.
Including 0,05 € for green tax

- +

Shipping date: 22-02-2024.

Orders placed before 12h (GMT+1) will generally be shipped the same day (working day).

Livraions depuis la france
Livraison depuis la france Livraison depuis la france Livraison depuis la france

Shipping from France
Billing in France
Technical support in France

Produit garantie 2 ans

Accessories for this product

Find here a selection of useful and/or essential accessories for this product. These are specially selected by the Audiophonics team according to the characteristics of the product.


More info

Shanling M1S

DAP Compact High Fidelity Digital Music Player DAC ES9038Q2M Bluetooth 5.0 LDAC 32bit 768kHz DSD MQA Silver

Shanling M1S DAP Baladeur Numérique Haute Fidélité Compact DAC ES9038Q2M Bluetooth 5.0 LDAC 32bit 768kHz DSD MQA Silver

Shanling offers with the M1S a technical and aesthetic evolution of the M1 high fidelity digital player. This S version benefits from an improved digital/analog conversion stage now based on an ESS ES9038Q2M chip as well as an updated Bluetooth receiver in version 5.0. Its appearance is also modernized while keeping its incredible compactness, a real distinctive element of the M1. Thus, the M1S is the ideal companion to accompany you both on the move and at home to offer you listening sessions of incredible quality.

Shanling M1S DAP Baladeur Numérique Haute Fidélité Compact DAC ES9038Q2M Bluetooth 5.0 LDAC 32bit 768kHz DSD MQA Silver

A DAP that fits in the palm of your hand

The first thing that stands out with this Shanling M1S is of course its particularly small size. Designed to follow you wherever you go, without taking up too much space, the DAP measures only 72x69x16mm. As for weight, the M1S weighs only 106g. It will be easily transportable so that you can enjoy your music.

However, Shanling does not make any concession on the ergonomics and integrates a beautiful high definition touch screen of 2.8" 640*480px. It will allow you to easily access your music and act on all available parameters. A screen placed behind a curved tempered glass and components protected by a superb CNC machined case 100% Aluminium.

Shanling M1S DAP Baladeur Numérique Haute Fidélité Compact DAC ES9038Q2M Bluetooth 5.0 LDAC 32bit 768kHz DSD MQA Silver

An updated system

If Shanling takes great care with the aesthetics of its product, this desire to offer a product that is both beautiful and easy to use is reflected in the software with the MTouch OS 2.0 operating system. Thus, the interface of the player allows a fast and easy navigation, and an easy access to the numerous features. This system is powered by an Ingenic X2000 3-core processor.

Shanling M1S DAP Baladeur Numérique Haute Fidélité Compact DAC ES9038Q2M Bluetooth 5.0 LDAC 32bit 768kHz DSD MQA Silver
Shanling M1S DAP Baladeur Numérique Haute Fidélité Compact DAC ES9038Q2M Bluetooth 5.0 LDAC 32bit 768kHz DSD MQA Silver

A technology at the service of sound

On the sound side, the M1S integrates an ESS ES9038Q2M DAC. These allow a digital / analog conversion of quality in all transparency. A converter associated with a section of powerful amplification with two RT6863 amplifier chips allowing output powers to 144mW @ 32 Ohm (Jack 3.5mm unbalanced) and 245mW @ 32 Ohm (Jack 4.4mm balanced).

A combination that allows this small DAP to offer an SNR of 118dB, a distortion of 0.0008% and to support sample rates up to PCM 32bit 768kHz, for a faithful and detailed reproduction.

Japanese KDS oscillators

The M1S is equipped with two crystal oscillators 90.3168Mhz / 98.304Mhz and a FGPA SS1712 chip to perfectly control all the data and allow the DAC to perfectly process the incoming audio signal. This is what allows the perfect restitution of HI-Res files.

Shanling M1S DAP Baladeur Numérique Haute Fidélité Compact DAC ES9038Q2M Bluetooth 5.0 LDAC 32bit 768kHz DSD MQA Silver

Unlimited connectivity

While the Shanling M1S has a 3.5mm jack connector to connect it to your headphones, it also offers Bluetooth 5.0 connectivity for a more comfortable use. A Bluetooth connectivity provided with Sony LDAC and Qualcomm aptX technologies. This first technology, the LDAC allows to enjoy in Bluetooth Hi-Res Audio files, up to 24bit 96kHz 4.5Mbps, where the classic Bluetooth would allow only 16bit 44.1Hz compressed. The second technology, the aptX allows it to obtain a transmission with less latency and more stable, to restore a clean signal.

But more than that, the M1S benefits from a bi-directional Bluetooth 5.0. So, if it can transmit to a speaker or headphones, it can also be used as a receiver, in order to take advantage of its amplification and its DAC, from a third party source.

Above all, the M1S can connect to a WiFi network to use AirPlay and DLNA technologies. A 4.4mm balanced jack is also available for exceptional headphone listening.

Shanling M1S DAP Baladeur Numérique Haute Fidélité Compact DAC ES9038Q2M Bluetooth 5.0 LDAC 32bit 768kHz DSD MQA Silver

Bi-directional USB-C

In the same way, this player also offers a bi-directional USB-C port. This one will be able, just like Bluetooth, to receive or send audio data. Ideal therefore to take advantage of the audio performance of the device.

Shanling M1S DAP Baladeur Numérique Haute Fidélité Compact DAC ES9038Q2M Bluetooth 5.0 LDAC 32bit 768kHz DSD MQA Silver

MQA Decoding

The M1S is capable of decoding MQA files and has dual Hi-Res certification; Hi-Res Audio and Hi-Res Wireless Audio.

A battery to follow you everywhere

The DAP integrates a 2100mAh battery for an autonomy of 14.5h in listening on the jack 3.5, 10.5h in listening on the jack 4.4 and 26h in bluetooth listening. Perfect to enjoy your music without interruption during all your travels.

Technical characteristics

SpEcifications
Product typeCompact digital music player (DAP)
DAC ChipsES9038Q2M
AOP Chips2* Ricore RT6863
ProcessorIngenic X2000 3-core
InputsBluetooth 5.0
1* USB-C
1* Slot Micro SD (2TB)
OutputsBluetooth 5.0
Wifi

1* Jack 3.5mm
1* Jack 4.4mm balanced
1* USB-C
SyncLinkEddict Player Application
Touch screen2.8" 640*440px
Battery2100mAh
Autonomy14.5h (jack 3.5mm)
10.5h (jack 4.4mm)
26h (bluetooth)
Supported Bluetooth codecsTransmitter : SBC, AAC, aptX, aptx HD, LDAC
Receiver : SBC, AAC, LDAC
Supported Wifi protocolsAirplay DLNA, OTA updates
Supported Hi-Res formats 32 bit 768Khz
DSD512
MQA
Formats supported by the USB DAC function32 bit 384Khz
DSD256
Supported file formatsDSD (.iso, .dsfl, .dff)
ISO (*ISO DST non pris en charge)
DXD
APE
FLAC
WAV
AIFF
ALF
DTS
MP3
WMA
AAC
OGG
ALAC
MP2
M4A
AC3
M3U
M3U8
OPUS
MQA
Filters7 digital filters
PowerUnbalanced output: 144mW @ 32Ω
Balanced output: 245mW @ 32Ω
Frequency responseUnbalanced output: 20Hz - 40kHz (-0.5dB)
Balanced output: 20Hz - 40kHz (-0.5dB)
THD+NUnbalanced output: 0.0007% @ 32Ω (A-Weighted @ 0.5V)
Balanced output: 0.0008% @ 32Ω (A-Weighted @ 1V)
Dynamic rangeUnbalanced output: 123dB @ 32Ω (A-Weighted)
Balanced output: 123dB @ 32Ω (A-Weighted)
Cross channelsUnbalanced output: 76dB @ 32Ω
Balanced output: 108dB @ 32Ω
SNRUnbalanced output: 122dB @ 32Ω (A-Weighted)
Balanced output: 118dB @ 32Ω (A-Weighted)
Noise floorUnbalanced output: 116 dB (A-Weighted)
Balanced output: 110 dB (A-Weighted)
Output impedanceUnbalanced output: < 0.4Ω
Balanced output: < 0.8Ω
General
Dimensions72*69*16mm
Weight106g
ColorSilver
Package1* Shanling M1S

Data sheet
InputUSB
InputMicro SD
InputBluetooth
OutputJack 4.4mm
OutputWiFi
OutputJack 3.5mm
OutputBluetooth
OutputUSB
DAC / ADC ChipES9038Q2M
Max sampling rate768kHz
Max sampling rateDSD512
Max sampling rateMQA
ColorBlack
