By buying this product you get 25 loyalty points
SMSL with the AL200 unveils a powerful Class D amplifier, integrating quality components such as an Infineon MA5332MS amplifier chip. The AL200 is capable of delivering 2x160W at 4Ω and 2x80W at 8Ω. It also incorporates a third-generation XMOS XU316 USB interface, as well as an MQA and MQA-CD decoder. It supports high sampling rates, up to PCM 32bit 768kHz and DSD256. Other features of the AL200 include a Bluetooth receiver chip, Jack 6.35mm TRS headphone output and 7 preset EQ. Compact and versatile thanks to its comprehensive connectivity, the SMSL AL200 amplifier will integrate easily into your HiFi system.
SMSL has turned to an Infineon MA5332MS Class D stereo amplifier chip for its AL200, ensuring excellent efficiency and low harmonic distortion. The AL200 delivers 2x160W of power at 4Ω or 2x80W at 8Ω, making it easy to drive a wide range of loudspeaker models.
The XMOS XU316 USB interface enables the AL200 to support sampling rates up to PCM 32bit 768kHz and native DSD up to DSD256. The AL200's USB-C input is therefore ideal for those wishing to transmit their music from a computer or smartphone in high quality. What's more, an MQA decoder makes it possible to enjoy these files and the MQA-CD format for sound as close as possible to the original studio recording.
For added versatility, the AL200 is equipped with a Bluetooth 5.0 receiver, so you can control the amplifier and broadcast your music remotely from a smartphone or tablet, for example.
On the front of the AL200 is a Jack 6.35mm TRS headphone output connected to a high-performance CS43131 DAC/headphone amplifier chip. This means the AL200 can easily drive demanding headphones with impedances of up to 300Ω.
Please note that the volume control systems for the headphone output and the speaker output are totally isolated and separate. Adjusting the volume on one output will therefore not affect the other, and vice versa.
The SMSL AL200 features 7 preset equalizers: Direct, Tone, SDB, Bass, Super Bass, Rock, Soft and Clear, as well as ±9dB tone control for bass and treble. This allows you to customize your sound according to your listening preferences and/or the type of music being played.
| 1 | Jack 6.35mm TRS headphone output |
| 2 | Bluetooth antenna |
| 3 | Screen |
| 4 | Volume control |
| 5 | Power input |
| 6 | Right channel speaker output |
| 7 | Left channel speaker output |
| 8 | Optical Toslink input |
| 9 | USB-C input |
| 10 | Coaxial input |
| 11 | Stereo RCA input |
Technical characteristics
| Specifications | |
|---|---|
| Product type | Amplifier |
| Amplification type | Class D |
| Inputs | 1* Stereo RCA 1* USB-C 1* Coaxial 1* Optical Toslink 1* Bluetooth |
| Outputs | Speaker terminals 1* Jack 6.35mm TRS headphone output |
| THD+N | 0.003% |
| SNR | 107dB |
| Channel separation | 98dB |
| Input sensitivity / Input impedance | 280mV / 22kΩ |
| Output power | 2x160W @ 4Ω 2x80W @ 8Ω |
| USB transmission | Asynchronous |
| USB compatibility | Windows 7/8/9/10/11 Mac OS Linux |
| MQA / MQA-CD decoder | USB Coaxial Optical Toslink |
| Supported sampling rates | USB : PCM up to 32bit 768kHz, Native DSD up to DSD256 Coaxial / Optical : PCM up to 24bit 192kHz, DSD64 (DoP) |
| General | |
|---|---|
| Supply voltage | AC 100-240V |
| Consumption | 40W |
| Dimensions (W*H*D) | 210*41*198mm |
| Weight | 1.78kg |
| Color | Black |
| Package | 1* SMSL AL200 1* Bluetooth antenna 1* Power cable |
| Input | USB |
| Input | SPDIF |
| Input | Bluetooth |
| Input | RCA |
| Input | Optical |
| Output | Jack 6.35mm |
| Output | Speaker terminal |
| Color | Black |
| Channel | 2 (Stereo) |
| Class | Class D / T |
| Amplifier chip | Infineon MA5332M |
| Power (W) | 160.0 |
| Remote Control | Yes |
