MUNDORF MCAP EVO OIL Capacitor 450V 2.7μF

MUNDORF MCAP EVO OIL Capacitor 450V 2.7μF
Average votes for this product
5.0 / 5

By buying this product you get 1 loyalty point


Reference : 7293
New product

13,50 €tax incl.

11,25 € tax excl.

- +

Shipping date: 29-03-2024.

Orders placed before 12h (GMT+1) will generally be shipped the same day (working day).

Livraions depuis la france
Livraison depuis la france Livraison depuis la france Livraison depuis la france

Shipping from France
Billing in France
Technical support in France

Produit garantie 2 ans

More info
Condensateur MUNDORF MCAP EVO OIL Condensateur 450V 2.7µF

Mundorf MCAP EVO Oil

The EVO series at Mundorf is intended to offer very high audio precision at a low price and with minimal space-use
Its polypropylene film (PP) is metallized with a layer of aluminum as thick as possible and with a proprietary geometry (Evolution Winding). The coil is then hand-mounted in a shell designed to reduce vibrations.

All these features contribute to a very lively audio reproduction that deeply respects microdynamics and stereophony. The whole EVO series is compliant to the highest standards of safety (self-healing).

Rigid wires for connections are long enough to allow vertical or horizontal mounting. Note that the shorter tab indicates the outer sheet of the capacitor.

This model belongs to the EVO Oil range introducing an oil impregnation step of the polypropylene (PP) films before building the coil. This maneuver removes residual air bubbles with formidable efficiency, which drastically reduces the electrical and mechanical losses associated with vibrations.

Dimensions

Capacitor Mcap EVO
Specifications
TypeCapacitor Mcap EVO
Capacitance2,70 µF
Voltage450V
Tolerance±3%
Diameter30
Lengthr21
Connct wire diameter0,8
Connect wire length (A)35
Connect wire length (B)50
Maximum room temp85°C
DielectricPolypropylene (PP)
MetallisationAluminum
Dielectric loss0.0002@1kHz · 0.0001@10kHz

Data sheet
Tolerance (%)3.0
Capacitor capacitance2.7
Rated voltage (V)450.0
Capacitor typeFilm capacitor
Capacitor formatAxial

Delivery

We deliver all over France, and internationally.
To find out the amount of shipping costs, simply go to your cart once you have added the desired products.
To discover our different services and delivery options, click on the following logos :

Only registered users can post a review. Log in or create an account .
Average votes
5.0 / 5
2 reviews
Why write products reviews ?
You can share your feelings about products and help other people by sharing your experience

Note :
 5/5
Date :
Magique
Sur mes klipsch le tweeter avait un son fatiguant , très métallique. Avec ce condensateur le son est devenu doux agréable. En bref , les poils des bras qui se dresse sur la musique.
 (2)
 (1)
This review has been posted for MUNDORF MCAP EVO OIL Capacitor 450V 2.7μF
Note :
 5/5
Date :
très bon condensateur intermédiaire entre MCap MKP et MCap Suprême
 (2)
 (0)
This review has been posted for MUNDORF MCAP EVO OIL Capacitor 450V 2.7μF
