MUNDORF MRESIST ULTRA Resistor 30W 1.5 Ohm

MUNDORF MRESIST ULTRA Resistor
The development of Mundorf MResist Ultra resistors is based on the excellent tonal properties of the copper-manganese foil. Compared to all wirewound resistors, this film offers lower inductance. The copper is significantly softer than the metal oxide used in MOX resistors.
Average votes for this product
5.0 / 5

By buying this product you get 2 loyalty points


Reference : 16124
New product

26,90 €tax incl.

22,42 € tax excl.

- +


Shipping date: 16-10-2024.

Orders placed before 12h (GMT+1) will generally be shipped the same day (working day).

Livraions depuis la france

Livraison depuis la france Livraison depuis la france Livraison depuis la france

Livraison depuis la France
Facturation France
SAV France

2 Years warranty

Accessories for this product

Find here a selection of useful and/or essential accessories for this product. These are specially selected by the Audiophonics team according to the characteristics of the product.


More info

Mundorf MResist ULTRA

Resistor 30W 1.5Ω

Mundorf MResist Ultra Résistance

The development of Mundorf MResist Ultra resistors is based on the excellent tonal properties of the copper-manganese foil. Compared to all wirewound resistors, this film offers lower inductance. The copper is significantly softer than the metal oxide used in MOX resistors. The natural resonances of the copper-manganese foil are therefore much less pronounced, which means that the distortions caused by crystallurgy and electroacoustics are significantly reduced. This is the reason why Mundorf MResist Ultra resistors have gained a prominent place among audio components in recent years: They are free of many of the distortions inherent in other resistor designs.

Technical characteristics

Specifications
Product typeResistance
Resistance1.5Ω
PowerIn free air : 3W
Fitted on a heatsink : 30W
Dimensions15.5 x 21.1 x 4.6mm
Connectors1.4 x 11.7 x 0.8mm
Temperature coefficient±30ppm/°C
Inductivity< 0.075µH
Dielectric strength500VAC
Temperature range-40°C / +130°C
Conductor materialManganin®
Core materialCuivre / PPS

Data sheet
Resistance (Ohm)1.5
Tolerance (%)N/A
Power (W)30.0
