[GRADE B] XDUOO TA-10R DAC AK4493 Tube Headphone Amplifier Class A Hybrid ECC82 32bit 384kHz DSD256

XDUOO TA-10R DAC AK4493 Tube Headphone Amplifier Class A ECC82 32bit 384kHz DSD256
-22%
Refurbished product - Grade B

xDuoo offers with its TA-10R a Class A tube DAC and headphone amplifier combo of great quality, offering both a beautiful musicality and a great precision in its sound restitution. The preamplifier stage using an ECC82/12AU7 tube and its Class A transistors allows it to develop a comfortable power of 2000mW under 32Ω which will be suitable for very many headphones on the market.

No customer reviews yet, login to write a review.


Reduced price!
Reference : 19601
Refurbished
Limited special offer

319,00 €tax incl.

-22%

249,00 €tax incl.

207,50 € tax excl.
Including 0,05 € for green tax

- +


Last items in stock !
Shipping date: 26-07-2024.

Orders placed before 12h (GMT+1) will generally be shipped the same day (working day).

Livraions depuis la france

Livraison depuis la france Livraison depuis la france Livraison depuis la france

Livraison depuis la France
Facturation France
SAV France

2 Years warranty

More info

Refurbished product - Grade B

Product reconditioned by manufacturer. Low screen brightness.

xDuoo TA-10R

DAC AK4493 Tube Headphone Amplifier Class A Hybrid ECC82 32bit 384kHz DSD256

xDuoo TA-10R DAC AK4493 Amplificateur Casque à Tube Class A ECC82 32bit 384kHz DSD256

xDuoo offers with its TA-10R a Class A tube DAC and headphone amplifier combo of great quality, offering both a beautiful musicality and a great precision in its sound restitution. The preamplifier stage using an ECC82/12AU7 tube and its Class A transistors allows it to develop a comfortable power of 2000mW under 32Ω which will be suitable for very many headphones on the market.

xDuoo TA-10R DAC AK4493 Amplificateur Casque à Tube Class A ECC82 32bit 384kHz DSD256
xDuoo TA-10R DAC AK4493 Amplificateur Casque à Tube Class A ECC82 32bit 384kHz DSD256

AK4493 DAC

The digital/analog conversion stage of the TA-10R is based on an AKM AK4493EQ DAC chip. This one is the insurance of a rich and precise reproduction, notably thanks to its Time Domain Jitter Eliminator technology, allowing to reduce considerably the jitter level. It also allows to support and read high resolution files, up to PCM 32bit 384kHz and DSD256 (USB).

This chip is associated with very good digital interfaces, with an XMOS chip for the USB input and a CS8422 chip for the SPDIF inputs.

Dual Clock & CPLD

The TA-10R features two low phase noise active clocks for incredibly accurate digital to analog conversion at any sample rate. These clocks are combined with a CPLD to process and adjust the data for perfect signal synchronization and minimum jitter.

xDuoo TA-10R DAC AK4493 Amplificateur Casque à Tube Class A ECC82 32bit 384kHz DSD256

Technical characteristics

Specifications
Product typeDAC
Headphone amplifier
DAC ChipAK4493
Amplifier typeClass A
TubeECC82
Inputs1x USB-B
1x Coaxial
1x Optical Toslink
1x Stereo RCA
Outputs1x SPDIF Coaxial
1x Stereo RCA
USB InterfaceXMOS XSA-U8A-64
Output power2000mW @ 32Ω
Supported sampling ratesUSB : PCM up to 32bit 384kHz, DSD up to DSD256, DXD up to 32bit 384kHz
Optical / Coaxial : PCM up to 24bit 192kHz, DSD DoP up to DSD64
ScreenOLED 0.96"
Frequency responseUSB / Optical/ Coaxial : 20Hz ~ 20kHz (±0.5dB)
Amp : 10Hz ~ 100kHz (±0.5dB)
SNR118dB
Crosstalk≥ 65dB
Compatible OSWindows 7 / 8 / 10
Mac OS X
iOS
Android
THD+N≤ 0.1% (1kHz)
General
Supply voltageAC 100-240V (power cable included)
Dimensions230 x 120 x 105mm
Housing materialAluminum
Weight1.5kg
ColorGray
Package1x xDuoo TA-10R
1x USB CAble
1x Jack 3.5mm / Jack 6.35mm adapter
1x Power cable

Data sheet
InputUSB
InputSPDIF
InputRCA
InputOptical
OutputXLR
OutputJack 6.35mm
OutputRCA
OutputCoaxial SPDIF
DAC / ADC ChipAK4493EQ
Max sampling rateDSD256
Max sampling rate384kHz
ColorGray
ClassTube amp
ClassClass A / AB
NetworkingNo
Remote ControlNo
Refurbished GradeGrade B
