ELIPSON CHROMA 400 Vinyl Turntable 33 / 45 / 78 RPM Ortofon OM-10E Black

ELIPSON CHROMA 400 Vinyl Turntable 33 / 45 / 78 RPM Ortofon OM-10E Black
The Chroma 400 turntable proposed by Elipson is a manual model with a belt drive. It is pre-equipped with an Ortofon OM-10E moving magnet cartridge and benefits from a brand new steel platter, a graduated counterweight, a carbon tonearm associated with its arm lift, but also a new platter axis system, an optimized motor and surround assembly and an improved electronic board.

No customer reviews yet, login to write a review.

By buying this product you get 44 loyalty points


Yes, notify me when available !
Reference : 16608
New product

449,00 €tax incl.

374,17 € tax excl.
Including 0,05 € for green tax

- +

Available on order
Livraions depuis la france
Livraison depuis la france Livraison depuis la france Livraison depuis la france

Shipping from France
Billing in France
Technical support in France

Produit garantie 2 ans

More info

Elipson Chroma 400

Vinyl Turntable 33 / 45 / 78 RPM Ortofon OM-10E Black

Elipson Chroma 400 Platine vinyle 33 / 45 / 78 tours OM-10E Noir

The Chroma 400 turntable proposed by Elipson is a manual model with a belt drive. It is pre-equipped with an Ortofon OM-10E moving magnet cartridge and benefits from a brand new steel platter, a graduated counterweight, a carbon tonearm associated with its arm lift, but also a new platter axis system, an optimized motor and surround assembly and an improved electronic board.

Elipson Chroma 400 Platine vinyle 33 / 45 / 78 tours OM-10E Noir

Made in France brand

Elipson is a French company, founded in 1938, designing and producing in France the Alpha, Omega and Chroma vinyl turntables. Thus, the design and the assembly of these products is carried out in Saint Fargeau in Yonne (Burgundy). In total, no less than 70% of the components of these models are manufactured in France (electronics, molded plastic, etc.). In addition, the turntables are entirely assembled by hand and each one is individually tested to guarantee optimal performance.

Carbon arm & Optimized engine

With the Chroma 400, Elipson offers an elegant turntable, simple to use and offering above all a beautiful musicality. The majority of the elements composing it have been designed with mechanical optimization in mind. Thus, its new carbon arm greatly minimizes vibrations and allows the signal transmitted by the cartridge to be carried without deterioration. The arm is also of the Chrome 400 and is also accompanied by its arm lift, allowing to lower and raise it smoothly.

The motor is also new, featuring a digital ASC (Auto Speed Control) drive, which allows for precise speed adjustment. This motor, mechanically suspended by an optimized system, also significantly reduces vibration. The new platter, meanwhile, combines with an improved rotation axis to ensure high inertia and a stable and constant reading speed.

Elipson Chroma 400 Platine vinyle 33 / 45 / 78 tours OM-10E Noir
Elipson Chroma 400 Platine vinyle 33 / 45 / 78 tours OM-10E Noir

Ortofon OM-10E cartridge

The Elipson Chroma 400 is equipped with an Ortofon OM-10E cell. This one has a diamond with an elliptical profile and ensures a frequency response between 20Hz and 25kHz with a channel separation of 22dB.

Technical characteristics

Specifications
Product typeVinyl turntable
Drive typeBelt
Rotation speeds33 tours
45 tours
78 tours
Arm materialCarbon
CartridgeMM Ortofon OM-10E
Frame materialMDF
Tray materialSteel
Centering pin materialAluminum
Ortofon OM-10E cartridge characteristics
Frame0.5"
Elliptical
Moving magnet
Output level4mV @ 1000Hz, 5cm/s
Channel separation22dB @ 1kHz
15dB @ 15kHz
Symmetry of the channels2dB @ 1kHz
Frequency response20Hz - 25kHz (-3dB)
20Hz - 20kHz (±2dB)
Tracking @ 315Hz, specified bearing pressure65µm
Lateral compliance25µm/mN
Radius of curvature of the tipr/R 8/18µm
Support pressure amplitude1.25 - 1.75g (12.5 - 17.5mN)
Recommended support pressure1.25g (12.5mN)
Cartridge weight6g
Internal impedance (DC current)750Ω
Internal impedance450Ω
Recommended load resistance47kΩ
Recommended load capacity200-600pF
Tracking angle20°
General
Dimensions450 x 380 x 120mm
Weight5.8kg
Color / FinishNoir laqué
Package1x Elipson Chroma 400
1x Mechanical scale
1x Power adapter
1x RCA cable with ground wire

Data sheet
ColorBlack
Cartridge typeMM (Moving Magnet)
Rotation speed45 RPM
Rotation speed33 RPM
Rotation speed78 RPM
