IAN CANADA RECLOCKPI Double I2S / DSD Reclocker Low Noise / Low Jitter

IAN CANADA RECLOCKPI Double I2S/DSD Reclocker Low Noise / Low Jitter
Ian Canada's ReClockPi is a high quality, low noise, low jitter dual reclocker module. It is designed to work with the FifoPi or any other digital audio device in synchronous mode to improve I2S/DSD signal quality.

Average votes for this product
5.0 / 5

By buying this product you get 9 loyalty points


Reference : 15350
New product

95,00 €tax incl.

79,17 € tax excl.

- +

Shipping date: 23-02-2024.

Orders placed before 12h (GMT+1) will generally be shipped the same day (working day).

Livraions depuis la france
Livraison depuis la france Livraison depuis la france Livraison depuis la france

Shipping from France
Billing in France
Technical support in France

Produit garantie 2 ans

Accessories for this product

Find here a selection of useful and/or essential accessories for this product. These are specially selected by the Audiophonics team according to the characteristics of the product.


More info

Ian Canada ReClockPi

Double I2S/DSD Reclocker Low Noise / Low Jitter

Ian Canada ReClockerPi Double ReClocker Faible Bruit / Faible Jitter I2S/DSD

Ian Canada's ReClockPi is a high quality, low noise, low jitter dual reclocker module. It is designed to work with the FifoPi or any other digital audio device in synchronous mode to improve I2S/DSD signal quality. It uses high speed discrete logic chips to correct the IR-drop problems of standard multi-bit reclockers, which can result in low and high level logic ripple. Thus, the ReClockPi reduces both noise and jitter.

Ian Canada ReClockerPi Double ReClocker Faible Bruit / Faible Jitter I2S/DSD

Key features :

  • The double reclocking discrete logic stage works as a signal conditioner.
  • Low noise. The noise of the output signal on the logic levels is much lower than the output signals of a conventional multi-bit re-clocker.
  • Low jitter. The jitter of the I2S/DSD output = MCLK jitter + additive jitter of the discrete flip-flops.
  • Independent shielding layer over the four-layer PCB to reduce EMI noise.
  • GPIO and dual U.FL I2S/DSD outputs.
  • Supports PCM up to 768kHz and DSD up to DSD1024.

Technical characteristics

Specifications
Product typeReclocker
InputsMCLK via U.FL
GPIO
OutputsI2S/DSD via U.FL
MCLK/2 via U.FL
GPIO
Max sampling ratesPCM up to 32bit 768kHz
DSD up to DSD1024
Dimensions75 x 56.5mm
Mounting holes spacing58 x 49mm
Ian Canada ReClockerPi Double ReClocker Faible Bruit / Faible Jitter I2S/DSD Ian Canada ReClockerPi Double ReClocker Faible Bruit / Faible Jitter I2S/DSD Ian Canada ReClockerPi Double ReClocker Faible Bruit / Faible Jitter I2S/DSD Ian Canada ReClockerPi Double ReClocker Faible Bruit / Faible Jitter I2S/DSD Ian Canada ReClockerPi Double ReClocker Faible Bruit / Faible Jitter I2S/DSD Ian Canada ReClockerPi Double ReClocker Faible Bruit / Faible Jitter I2S/DSD

Data sheet
InputGPIO
InputU.FL
OutputGPIO
OutputI2S
OutputU.FL
DAC / ADC ChipNC
Max sampling rate768kHz
Max sampling rateDSD1024

Delivery

We deliver all over France, and internationally.
To find out the amount of shipping costs, simply go to your cart once you have added the desired products.
To discover our different services and delivery options, click on the following logos :

Only registered users can post a review. Log in or create an account .
Average votes
5.0 / 5
2 reviews
Why write products reviews ?
You can share your feelings about products and help other people by sharing your experience

Note :
 5/5
Date :
Excellent reclock avec FIFO PI Q3
Très bon upgrade que ce recloker en plus du FIFO PI Q3 de Ian canada. Pour ma part c'est ma dernière modif après avoir installé le FIFO PI Q3 ainsi que des horloges acusillicon et des AOP de chez Sparkos Labs en sortie de mon filtre actif Najda, voir mes avis à ce sujet. Ce que je peux dire c'est que je ne pensais pas avoir un gain réel et bien si, il est certes plus faible que les modifs précédentes mais tout de même il y a un gap. Le plus frappant c'est la sensation de gagner en émotion comme si on retrouvais la chaleur de l'analogique. TOut est plus juste du grave à l'aigu mais surtout mes Altec 414 ont un grave très tendu parfaitement juste comme si j'avais des 416. A achetter lorsque l'on a déjà fait pas mal de modif et que l'on souhaite encore gagné un peu.
 (1)
 (0)
This review has been posted for IAN CANADA RECLOCKPI Double I2S / DSD Reclocker Low Noise / Low Jitter
Note :
 5/5
Date :
Clearly makes a difference
Very nice improvement to the FifoPi MK3. Highly recommended.
 (0)
 (0)
This review has been posted for IAN CANADA RECLOCKPI Double I2S / DSD Reclocker Low Noise / Low Jitter
