JANTZEN AUDIO SUPERIOR Z-CAP Capacitor 1200V 0.22µF

JANTZEN AUDIO SUPERIOR Z-CAP Capacitor 1200V 0.22µF
Jantzen Audio's Superior Z-Cap range consists of high-end, non-polarized capacitors designed specifically for audio to allow your audio system to reproduce every nuance, every detail of the signal, while maintaining unparalleled naturalness and realism.
Average votes for this product
5.0 / 5

No loyalty points for this product.


Reference : 10014
New product

8,50 €tax incl.

7,08 € tax excl.

- +


Shipping date: 09-10-2024.

Orders placed before 12h (GMT+1) will generally be shipped the same day (working day).

Livraions depuis la france

Livraison depuis la france Livraison depuis la france Livraison depuis la france

Livraison depuis la France
Facturation France
SAV France

2 Years warranty

More info

Jantzen Audio Superior Z-Cap

Capacitor 1200V 0.22µF

Jantzen Audio Superior Z-Cap Condensateur

Jantzen Audio's Superior Z-Cap range consists of high-end, non-polarized capacitors designed specifically for audio to allow your audio system to reproduce every nuance, every detail of the signal, while maintaining unparalleled naturalness and realism.

In particular, they are recommended for use as a capacitor for high-end tweeters or as a coupling capacitor in an amplifier. All Jantzen Audio Z-Cap capacitors have a nitrogen filling that allows the amount of foil per capacitor to be increased while eliminating the risk of evaporation that can be found in capacitors using oil or other dielectric fluids.

Superior Z-Cap capacitors are not polarized. The signal can therefore pass in both directions, without impacting the reproduction or sound performance.

Technical characteristics

Specifications
Product typeCapacitor (Super MKP, non-polarized)
Capacity0.22µF
Voltage1200VDC
Tolerance±2%
DielectricPolypropylene foil
ConstructionDual foil
Axial
ElectrodeAluminum metallized, vacuum deposited
Wires materialTinned OFC Copper
Dielectric absorption factor< 0.5% @ 20°C
Dielectric thicknessPB=6µm
Self-inductance0nH
Insulation resistance> 100000MΩ @ 20°C
Temperature range-55°C to +85°C
Metal layer thicknessPB=0.4µm
Metal layer conductivityPB=2.5Ω/cm²
Général
DimensionsØ22 x 43mm
Poids24g

Data sheet
Tolerance (%)2
Capacitor capacitance (µF)0.22
Rated voltage (V)1200.0
Capacitor typeFilm capacitor
Capacitor formatAxial

Delivery

We deliver all over France, and internationally.
To find out the amount of shipping costs, simply go to your cart once you have added the desired products.
To discover our different services and delivery options, click on the following logos :

Only registered users can post a review. Log in or create an account .
Average votes
5.0 / 5
6 reviews
Why write products reviews ?
You can share your feelings about products and help other people by sharing your experience

Note :
 5/5
Date :
Excellent !
Les condensateurs Jantzen de la série Z-Cap Superior sont vraiment excellents, aussi bien pour le filtrage des haut-parleurs que pour améliorer les circuits électroniques hifi de tout type.
La musicalité progresse nettement, n'hésitez pas à les utiliser.
Livraison rapide, bravo Audiophonics.
 (0)
 (0)
This review has been posted for JANTZEN AUDIO SUPERIOR Z-CAP Capacitor 1200V 0.22µF
Note :
 5/5
Date :
Excellent, vraiment !
Toujours aussi excellents ces condensateurs, que ce soit pour du filtrage HP ou pour remplacer des condensateurs dans des éléments électroniques haute-fidélité.
Celui-ci remplace un condo MKP chinois 0.22 µF dans mon préampli phono MM à tubes (1 tube ECL82 + 1 tube 6z5p + 2 tubes 12au7 + 2 tubes 12ax7) clone d'un Audio Note et le résultat est là.
Livraison express, félicitations à Audiophonics.
 (0)
 (0)
This review has been posted for JANTZEN AUDIO SUPERIOR Z-CAP Capacitor 1200V 0.22µF
Note :
 5/5
Date :
Parfait
Très bon condos,utilisé pour du filtrage d'enceintes ou découplage d'amplis à tubes.ils ne rajoutent rien,et n'enlève rien,très bon rapport qualité prix,cela s'entend à l'écoute c'est indéniable.
 (0)
 (0)
This review has been posted for JANTZEN AUDIO SUPERIOR Z-CAP Capacitor 1200V 0.22µF
Note :
 5/5
Date :
Tout simplement le meilleur rapport qualité-prix que je connaisse
Le rendu à un petit quelque chose d'analogique...
 (0)
 (0)
This review has been posted for JANTZEN AUDIO SUPERIOR Z-CAP Capacitor 1200V 0.22µF
Note :
 5/5
Date :
Excellent
Pricy, but best sounding caps for the money. I use them also as kathode bypass caps in my SET tube amp.
 (0)
 (0)
This review has been posted for JANTZEN AUDIO SUPERIOR Z-CAP Capacitor 1200V 0.22µF
