DAYTON AUDIO PCS12-4 Subwoofer Speaker

The Dayton Audio PCS12-4 is a 30.48cm (12") paper cone subwoofer speaker, designed for DIY projects and multi-way systems seeking deep bass extension, high output level and easy integration. Its polypropylene-coated paper cone, combined with an inverted dust cap of the same finish, produces energetic bass while retaining a sober appearance, while the 30 Hz resonance frequency promotes an extended response in a properly designed enclosure.

With a sensitivity of 90.6 dB, an impedance of 4 Ω, a 7 mm Xmax and a power handling of 180 W RMS, it delivers significant impact without requiring oversized amplification. Its wide-roll rubber surround accompanies the movements of the cone in order to maintain controlled excursion, while the fully vented motor improves heat dissipation during extended listening sessions. Finally, its low-profile stamped steel basket simplifies installation in a dedicated enclosure or in a custom build, to effectively reinforce the bass range of an audio system.
