MUNDORF MCAP EVO OIL Capacitor 450V 3.9μF

MUNDORF MCAP EVO OIL Capacitor 450V 3.9μF
Average votes for this product
4.7 / 5

By buying this product you get 1 loyalty point

Reference : 7295
New product

10,75 €tax excl.

- +

Shipping date: 07-12-2021.

Orders placed before 11AM (GMT+1) will generally be shipped the same day (working day).

Livraions depuis la france
Livraison depuis la france Livraison depuis la france Livraison depuis la france

Shipping from France
Billing in France
Technical support in France

Produit garantie 2 ans
More info
Condensateur MUNDORF MCAP EVO OIL Condensateur 450V 3.9µF

Mundorf MCAP EVO Oil

The EVO series at Mundorf is intended to offer very high audio precision at a low price and with minimal space-use
Its polypropylene film (PP) is metallized with a layer of aluminum as thick as possible and with a proprietary geometry (Evolution Winding). The coil is then hand-mounted in a shell designed to reduce vibrations.

All these features contribute to a very lively audio reproduction that deeply respects microdynamics and stereophony. The whole EVO series is compliant to the highest standards of safety (self-healing).

Rigid wires for connections are long enough to allow vertical or horizontal mounting. Note that the shorter tab indicates the outer sheet of the capacitor.

This model belongs to the EVO Oil range introducing an oil impregnation step of the polypropylene (PP) films before building the coil. This maneuver removes residual air bubbles with formidable efficiency, which drastically reduces the electrical and mechanical losses associated with vibrations.


Capacitor Mcap EVO
TypeCapacitor Mcap EVO
Capacitance3,90 µF
Connct wire diameter0,8
Connect wire length (A)35
Connect wire length (B)50
Maximum room temp85°C
DielectricPolypropylene (PP)
Dielectric loss0.0002@1kHz · 0.0001@10kHz
Data sheet
Tolerance (%)3.0
Capacitor capacitance3.9
Rated voltage (V)450.0
Capacitor typeFilm capacitor
Capacitor formatAxial
We deliver all of France, and internationally.
To discover the amount of the shipping costs, you just have to go in your shopping cart once the desired products added.
To discover our different services and delivery options, click on the following logos:
Colissimo - TNT - SoColissimo
Only registered users can post a review. Log in or create an account .
Average votes
4.7 / 5
3 reviews
Why write products reviews ?
You can share your feelings about products and help other people by sharing your experience

Note :
Date :
Condensateur mundorf oil
Produit conforme à ma commande.
Pas encore monté.
Je suis surpris de la rapidité de la prise en charge de ma commande et de l'expédition, bravo pour ce professionnalisme.
Je suis super satisfait de tous les articles achetés chez Audiophonics
Philippe. D
This review has been posted for MUNDORF MCAP EVO OIL Capacitor 450V 3.9μF
Note :
Date :
Mundorf MCAP EVO OIL 3,9uF 450v
Pouvez-vous me dire quand vous effectuerez l'envoi en attente?
This review has been posted for MUNDORF MCAP EVO OIL Capacitor 450V 3.9μF
Note :
Date :
Maxime D.
I just compared Mundorf EVO Aluminium Oil 3.9uf 450V with my currently installed Audyn Q4 3.9uf 400V in tweeter section. Mundorf disappointed me. Yes, it is audible that Mundorf has significantly lower distortion in comparison to Q4, but Mundorf sounds monotonously and overly smooth, even were it is not needed. Mundorf has a poor macrodynamics in comparison to Q4, but good microdynamics. I've listened Adele - Take It All and Lenny Kravitz - Rock And Roll Is Dead, and both tracks no movement of sound sources, it sounds like a big pile of good quality sound, but not as exciting performance.
This review has been posted for MUNDORF MCAP EVO OIL Capacitor 450V 3.9μF
