WBT-0102Ag RCA Plug Nextgen Pur Silver 75 Ohms Ø9mm (Set x4)

WBT-0102Ag Connecteurs RCA Nextgen Argent (x4)
The RCA connectors WBT-0102Ag allow the design of high-end finished cables thanks to a high quality design optimized for performance. The contacts are made of pure silver with a maximum conductivity level for optimal signal transmission.

Average votes for this product
2.0 / 5

By buying this product you get 20 loyalty points


Yes, notify me when available !
Reference : 8645
New product

207,50 €tax excl.

- +

Available on order
Livraions depuis la france
Livraison depuis la france Livraison depuis la france Livraison depuis la france

Shipping from France
Billing in France
Technical support in France

Produit garantie 2 ans

More info

WBT-0102Ag

RCA Connectors Nextgen Silver 75Ω Ø9mm (Set x4)

WBT-0102Ag Connecteurs RCA Nextgen Argent 75Ω Ø9mm (Set x4)

The RCA connectors WBT-0102Ag allow the design of high-end finished cables thanks to a high quality design optimized for performance. The contacts are made of pure silver with a maximum conductivity level for optimal signal transmission. Contacts with several lamellae are machined by high-precision machines with diamond drill bits. This design allows a high contact pressure to maximize conductivity even more. The silver contacts have been treated to avoid any corrosion detrimental to the quality of the contact.

A particular feature of this model is its bandwidth of up to 200MHz, well beyond the usual standard for RCA connectors. The connector body is made of copper alloy and the dielectric elements of Ultramid, a particularly resistant plastic. They are able to accommodate cables with a maximum diameter of Ø9mm.

Diagram

WBT-0102Ag Connecteurs RCA Nextgen Argent 75Ω Ø9mm (Set x4)
1Fine Silver plus contact
2Fine Silver minus contact
3Ultramid plus contact dielectric
4Vectra S135 minus contact dielectric
5Copper Alloy holding unit
6Copper Alloy body
7Copper Alloy cap
8Desmopan marking ring
9Copper Alloy Torx M4x4 screw

Technical characteristics

Specifications
Product typeMale RCA connectors
Max cable diameterØ9mm
Mounting typeTo solder
Contacts materialFine Silver
+ Contact dielectric materialFiber Glass reinforced Ultramid
- Contact dielectric materialVectra S135
Body, cap and screw materialCopper alloy
Holding unit materialCopper alloy
Contacts platingPure Platinum 0.4µm
Permanent currentId > 10A
Transition resistanceRü < 0.1mΩ
Contact resistanceRbi, Rba < 0.45mΩ
CapacitanceC ≅ 2.82pF
Insulation resistanceRia, Rag > 1.3·109 (conductor/conductor, conductor/chassis)
ImpedanceZ = 75Ω up to 200MHz
General
Total dimensionsØ13.6 x 51mm
ColorBlack
QuantitySold per 4 (2 white marked connectors, 2 red marked connectors)

Data sheet
PlatingNone
Max cable diameter (mm)9.0
Mounting typeTo screw
ConnecticMale
Contacts Material (Connector)Silver
Contacts Plating (Connector)None

Delivery
We deliver all of France, and internationally.
To discover the amount of the shipping costs, you just have to go in your shopping cart once the desired products added.
To discover our different services and delivery options, click on the following logos:
Colissimo - TNT - SoColissimo
Only registered users can post a review. Log in or create an account .
Average votes
2.0 / 5
1 reviews
Why write products reviews ?
You can share your feelings about products and help other people by sharing your experience

Note :
 2/5
Date :
Montage plus que délicat
Sur quatre connecteurs, j’ai dû en jeter deux parce qu’une des deux pattes d’encrages s’est cassée par deux fois lorsque j’ai voulu désolidariser la partie plastique pour exécuter le soudage, qui n’est pas réalisable sans cela.
De plus on ne peut pas utiliser un câble supérieur à 8 mm de diamètre, au delà si le câble rentre bien jusqu’à 9 mm, il n’en ressort pas ce qui est selon moi problématique pour souder.

J’ai quand même pu fabriquer un câble numérique pour relier un lecteur DC à un DAC. J’ai utiliser un câble Furutech de 8mm de diamètre, j’avais aussi pris un Neotech de 8,4 mm mais cela ne passait plus et de toute façon comme je l’ai mentionné ci-dessus deux connectiques étaient dégradées donc je ne l’aurai pas monté dans tous les cas.

Niveau sonore, bien que non rôdé il y a bien une plus value dans ce nouveau câble SPDif.

Bref, sur le principe les connecteurs sont de bonne qualité, mais en pratique une faiblesse au niveau des pattes de démontages les rendent inopérants ce qui est inacceptable au vu du prix.

Jm,

 (2)
 (0)
This review has been posted for WBT-0102Ag RCA Plug Nextgen Pur Silver 75 Ohms Ø9mm (Set x4)
