Module Amplificateur Stéréo UPC2581 IRFP9240 Class AB 2x 125W 4 Ohm

Module Amplificateur Stéréo UPC2581 IRFP9240 Class AB 2x 125W / 4 Ohm
This Class AB amplifier module allows to develop a consequent power of 2x 125W in a compact form factor. It is based on the use of 25C5171, 2SA193, 2SC5171 transistors (four transistors in total), IRFP240 and IRFP9240 power MOSFETs and a UPC2581 voltage amplifier chip.

No customer reviews yet, login to write a review.

By buying this product you get 4 loyalty points


Yes, notify me when available !
Reference : 15526
New product

41,58 €tax excl.

- +

Available on order
Livraions depuis la france
Livraison depuis la france Livraison depuis la france Livraison depuis la france

Shipping from France
Billing in France
Technical support in France

Produit garantie 2 ans

More info

Amplifier board

Stereo UPC2581 IRFP9240 Class AB 2x 125W 4 Ohm

Module Amplificateur Stéréo UPC2581 IRFP9240 Class AB 2x 125W / 4 Ohm

This Class AB amplifier module allows to develop a consequent power of 2x 125W in a compact form factor. It is based on the use of 25C5171, 2SA193, 2SC5171 transistors (four transistors in total), IRFP240 and IRFP9240 power MOSFETs and a UPC2581 voltage amplifier chip. It benefits from a careful design with a protection circuit for loudspeakers using a UPC1237 chip and Omron relays but also Siemens decoupling capacitors and metal film resistors with a tolerance of 1%. This architecture allows to provide a high power while promoting a clear and detailed sound reproduction.

Technical characteristics

Specifications
Product typeAmplifier board
Amplifier typeClass AB
Output power2x 125W
Output impedance4-8Ω
THD< 0.002%
InputsAnalog input on PCB connector
OutputsSpeaker output on screw terminal
General
Supply voltage36VAC (on screw terminal)
Dimensions168 x 85mm

Data sheet
InputPCN Connector
OutputScrew terminals
ClassClass A / AB
Amplifier chipTransistors
Power (W)125.0
