FERRUM ERCO GEN 2 Balanced DAC ES9028PRO

FERRUM ERCO Balanced DAC ES9028PRO 32bit 384kHz DSD256
Ferrum unveils with its Erco an incredible DAC, taking advantage of both the Hypsos power supply and the OOR preamplifier technologies, adding an extremely powerful digital/analog conversion stage.

No customer reviews yet, login to write a review.

By buying this product you get 197 loyalty points


Reference : 16008
New product

1 975,00 €tax incl.

1 645,83 € tax excl.
Including 0,05 € for green tax

- +

Shipping date: 30-04-2024.

Orders placed before 12h (GMT+1) will generally be shipped the same day (working day).

Livraions depuis la france
Livraison depuis la france Livraison depuis la france Livraison depuis la france

Shipping from France
Billing in France
Technical support in France

Produit garantie 2 ans

Accessories for this product

Find here a selection of useful and/or essential accessories for this product. These are specially selected by the Audiophonics team according to the characteristics of the product.


More info

Ferrum Erco gen 2

Balanced DAC ES9028Pro 32bit 384kHz DSD256

Ferrum Erco DAC Symétrique ES9028Pro 32bit 384kHz DSD256

Ferrum unveils with its Erco an incredible DAC, taking advantage of both the Hypsos power supply and the OOR preamplifier technologies, adding an extremely powerful digital/analog conversion stage. This desktop DAC can be used with headphones or powered speakers, turning your computer into a high quality audio system. The Erco has been designed to provide uncolored sound, very low distortion and high dynamics.

Updated version: Ferrum ERCO Gen 2!

Closer to your music: Ferrum's ERCO DAC moves to generation 2 with a massive firmware update and improved circuitry!

The new ERCO generation approaches the exceptional level of the brand's flagship WANDLA. With the complete reprogramming of the device's firmware, combined with crucial changes to the analog circuitry, Ferrum offers a more modern, high-performance version of its ERCO.

The complete reprogramming of the ERCO involves inserting the new bootloader deep into its memory, and goes far beyond a simple firmware update. Proceeding from the output, the ERCO Gen 2 DSP becomes equivalent to that of the WANDLA, bringing features such as support for PCM 768kHz, DSD512, improved DAC performance and the inclusion of the WANDLA digital filter.

Analog enhancements for ERCO Gen 2

ERCO Gen 2's I/V converter benefits from the experience acquired by the brand with the development of the WANDLA. This update gives the device a more detailed sound signature.

Digital enhancements for ERCO Gen 2

As the ERCO's digital section is similar to that of the brand's SERCE card, Ferrum has been able to port the complete SERCE software stack to the ERCO. The same HQ Apodizing digital filter as on the WANDLA has been added, the ESS filters have been bypassed, and the ERCO is now also capable of decoding 768kHz PCM and DSD512 streams. Intermodulation and intersampling distortions have been reduced, and output levels adjusted to meet current standards.

Summary of ERCO Gen 2 improvements:

  • Software architecture based on SERCE
  • Upgrading the I/V floor
  • PCM 768kHz support (USB only)
  • DSD512 support
  • DSP update (same as WANDLA)
  • MQA decoder and renderer only work with MQA signals
  • Replacing the ESS filter with an HQ Apodizing filter
  • First-level filters disabled for high sampling frequencies (≥ 352.8kHz)
  • Enhanced DAC chip configuration
  • Changes from original ERCO firmware v1.0.3
  • Adjusted signal level (2V unbalanced / 4V balanced RMS)
  • Reduced intermodulation distortion for full-scale signals

A high-end desktop DAC

An optimized circuit : A perfect combination of Ferrum technologies integrated into the sin of the high quality DAC, the Erco provides three digital inputs and one analog input.

Fully balanced : The Erco's circuits are totally balanced. The DAC offers both a balanced XLR input and unbalanced RCA.

Easy to use : The Erco has only 3 buttons on its front panel to control the most important functions of the device.

Proprietary amplifier stage : Ferrum's converter incorporates a balanced amplifier stage, using modified integrated circuits.

Optimized digital inputs : The USB, coaxial and optical interfaces have been specially programmed and optimized to provide excellent audio performance.

MQA decoding : The Erco benefits from an MQA decoder using a powerful ARM processor.

A perfect transparency : The entire internal design of the Erco focuses on its ability to provide a highly transparent sound reproduction.

An ideal ally of the Hypsos : While the Erco offers excellent performance on its own, it has also been designed to work perfectly with the Ferrum Hypsos power supply, to be connected using the proprietary FPL (Ferrum Power Link) cable. This combination unlocks the full potential of the Erco.

Technical characteristics

Specifications
Product typeDAC
DAC ChipES9028Pro
Inputs1x Stereo RCA
1x USB-C
1x Optical Toslink
1x Coaxial
Outputs1x Balanced Jack 4.4mm TRRRS headphone output
1x Single-ended Jack 6.35mm headphone output
1x Balanced XLR line output
1x Single-ended RCA line output
Headphone output gainBalanced : -5.8dB, +6dB, +17.8dB
Single-ended : -11.8dB, 0dB, 11.8dB
Supported sampling ratesPCM up to 32bit 384kHz
DSD up to DSD256
MQA
Volume controlAnalog with bypass function
Frequency response10Hz - 30kHz (±0.05dB)
10Hz - > 200kHz (±1dB)
Single-ended output power300mW @ 300Ω
1.7W @ 50Ω
Balanced output power1.2W @ 300Ω
6.1W @ 50Ω
Single-ended output THD< 0.00032% / -110dB, 1mW @ 16Ω
< 0.00057% / -105dB, 100mW @ 16Ω
Balanced output THD< 0.00018% / -115dB, 1mW @ 16Ω
< 0.00018% / -115dB, 100mW @ 16Ω
Dynamic rangeAnalog : 130dB (A-Weighted)
Digital : 120dB (A-Weighted)
Input impedance47kΩ
Output impedanceSingle-ended : 22Ω via preamplifier
Balanced : 44Ω via preamplifier
Headphone output impedance< 0.3Ω
General
Power supply22-30VDC via Jack DC 5.5/2.5mm or 4-pin FPL proprietary connector
Consumption< 15W
Dimensions21.7 x 20.6 x 5cm
Weight1.8kg

Data sheet
InputRCA
InputOptical
InputUSB
InputSPDIF
OutputRCA
OutputJack 6.35mm
OutputXLR
OutputJack 4.4mm
DAC / ADC ChipES9028PRO
Max sampling rate384kHz
Max sampling rateDSD256
ColorBlack
NetworkingNo
Remote ControlN/A
