MATRIX MINI-I PRO 2S ES9026Pro DAC 32bit 384kHz DSD DXD & Headphone Amplifier Black

MATRIX MINI-I PRO 2S ES9026Pro DAC 32bit 384kHz DSD DXD & Headphone Amplifier Black
The Matrix Mini-I Pro 2S inherits the qualities of its predecessors, while this time incorporating an ES9026Pro converter, offering enhanced performance. It also includes preamp and headphone amp section.

No customer reviews yet, login to write a review.

By buying this product you get 63 loyalty points


Reference : 12370
New product

634,90 €tax incl.

529,08 € tax excl.
Including 0,01 € for green tax
Available

- +

Shipping date: 21-06-2018.

Orders placed before 1pm (GMT+1) will be shipped the same day (working day).

Produit garantie 2 ans

Accessories


More info

Mini-i Pro 2S

32Bit/384kHz DAC DSD DXD & Headphone amplifier

Matrix Mini-I Pro 2S

Ever more efficient

After about a year of waiting, Matrix launches its "S" model which joins the range of Mini-I DAC's. With the same design as the Mini-I Pro 2, it brings a real power boost based on an ES9026PRO converter. This means that the excellent performances already achieved by the Mini-I Pro 1 of the name or by the DAC of the Mini-I series in general can be extended even further.

ESS Sabre 9026Pro

The brand new 8-channel ES9026Pro converter provides great optimization of the integrated DSP compared to its predecessor, the ES9016S, while providing a better user experience.

ES9026Pro
Connectique full dsd

Full DSD Connectors

Instead of limiting DSD support only via the USB port, Matrix allows you to take advantage of a full DSD connection right now. Thus, the Mini-I Pro 2S supports DoP support via the Optical, Coaxial and AES/EBU inputs, allowing you to take advantage of the DoP function of your drives.

Different filters for different listening

With more than 7 types of PCM digital filters, you can select a filter curve to refine the returned timbre. Thus, everyone can find a mode adapted to their listening needs.

Filtres digitaux
Préamplificateur

Integrated Preamplifier

The line output can be adjusted with a volume gain up to +18dB. In this way, it is no longer necessary to add an external pre-amplifier to use active low gain speakers. Of course, the Mini-I Pro 2S can work with a power amplifier for a more flexible use and more in accordance with your needs.

Bluetooth aptX

For easy and comfortable listening, the Matrix Mini-I Pro 2S lets you stream your files in Bluetooth. It therefore incorporates the aptX standard, which has the advantage of protecting your files from Bluetooth damage.

Bluetooth aptX
Structure aluminium

An elegant design

The Mini-I Pro 2S inherits the elegant design of the Mini-I series DACs. CNC-machined with anodized surface, it announces at a glance a quality product.

Remote Control

The DAC, supplied with a remote control, wins with this accessory a real plus in terms of ergonomics. This allows you to switch the unit on/off, control the volume or select the active source.

Télécommande

Technical characteristics

Digital outputs
AESPCM 16-24Bit /44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz
DSD DSD64 (DoP)
CoaxialPCM 16-24Bit /44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz
DSD DSD64 (DoP)
OptiquePCM 16-24Bit /44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz
DSD DSD64 (DoP)
USBPCM 16-32Bit /44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz, 352.8kHz, 384kHz
DSD DSD64/DSD128 (DoP) DSD64/DSD128/DSD256 (ASIO Native)
BluetoothPCM 16Bit/48kHz aptX/AAC/SBC
Version Bluetooth4.0
Bluetooth frequency band2.402GHz - 2.480GHz
Bluetooth PowerClass II
Bluetooth max. operating distance10-15m
Delay<20ms
Analog outputs
XLRSNR : > -123dB 20Hz-20kHz A-Weighting
THD+N : <0.0003% @ 1kHz A-Weighting
Réponse en fréquence : 20Hz - 20kHz (+0.01dB/-0.02dB)
Diaphonie : > -130dB @ 1kHz
Sortie XLR : 4Vrms fixe at 0dBFS Mode DAC / 0-4Vrms ajustable at 0dBFS Mode Preamp
RCASNR : > -120dB 20Hz-20kHz A-Weighting
THD+N : < 0.0005% @ 1kHz A-Weighting
Réponse en fréquence : 20Hz - 20kHz (+0.01dB/-0.02dB)
Diaphonie : > -126dB @ 1kHz
Sortie RCA : 2Vrms fixe at 0dBFS Mode DAC / 0-2Vrms ajustable at 0dBFS Mode Preamp
Headphone output
SNR>-116dB 20Hz-20kHz A-Weighting
THD+N<0.0007% @ 1kHz A-Weighting à 300ohms 25mW
Réponse en fréquence20Hz-20kHz (+0dB/-0.1dB)
Diaphonie>-126dB @1kHz
Impédance sortie casque10 Ohms
Puissance sortie casque820mW @ 33ohms at THD+N=0.1%
210mW @ 300ohms at THD+N=0.1%
110mW @ 600ohms at THD+N=0.1%
General
CompatibilityWindows 7/8/8.1/10 (driver required)
Mac OS X10.6.4 and later versions
Most of the Android devices can be used with OTG cable
iOS devices can be used with Camera Kit
Power voltage230V position is fit for AC220V-240V 50/60Hz
115V position is fit for AC100V-120V 50/60Hz
Power Consumption< 10W
Dimensions168 x 205 x 47mm
Weight1.3kg
Accessories1x Quick Start Guide
1x RM2 Remote Control
1x Bluetooth Antenna
1x Power Cord
1x USB Cable

Data sheet
ComponentEs9026PRO
InputUSB XMOS
InputOptical
InputSPDIF
ColorNoir
Channel2 channels (Stéréo)
