TOPPING E50 Balanced DAC ES9068AS XMOS XU216 MQA 32bit 768kHz DSD512 Black

TOPPING E50 Balanced DAC ES9068AS XMOS XU216 MQA 32bit 768kHz DSD512 Black
Topping offers with its E50 a compact and very powerful DAC, using proven audio components widely recognized by audiophiles. This one is indeed based on an ESS ES9068AS digital/analog conversion chip as well as an XMOS XU216 USB interface, allowing it to read high resolution files but also to decode MQA files.

No customer reviews yet, login to write a review.

By buying this product you get 22 loyalty points


Reference : 15587
New product

224,17 €tax excl.

Including 0,04 € for green tax

- +

Shipping date: 08-12-2021.

Orders placed before 11AM (GMT+1) will generally be shipped the same day (working day).

Livraions depuis la france
Livraison depuis la france Livraison depuis la france Livraison depuis la france

Shipping from France
Billing in France
Technical support in France

Produit garantie 2 ans

Accessories for this product


More info

Topping E50

DAC ES9068AS XMOS XU216 Symétrique MQA 32bit 768kHz DSD512 Black

Topping E50 DAC ES9068AS XMOS XU216 Symétrique MQA 32bit 768kHz DSD512

Topping offers with its E50 a compact and very powerful DAC, using proven audio components widely recognized by audiophiles. This one is indeed based on an ESS ES9068AS digital/analog conversion chip as well as an XMOS XU216 USB interface, allowing it to read high resolution files but also to decode MQA files. It also benefits from a balanced output on TRS connectors.

Topping E50 DAC ES9068AS XMOS XU216 Symétrique MQA 32bit 768kHz DSD512
Topping E50 DAC ES9068AS XMOS XU216 Symétrique MQA 32bit 768kHz DSD512

ESS ES9068ASDAC

The E50's digital-to-analog conversion stage uses the latest ESS ES9068AS DAC chip to deliver a transparent and richly detailed sound. The device ensures excellent performance with a very low distortion of 0.00009% or a dynamic range of 126dB.

USB XMOS XU216

The USB interface of the Topping E50 uses a second generation XMOS XU216 16-core chip with custom Thesycon driver. Associated with the ES9068AS DAC, this combination allows a perfect sound neutrality but also the support of high resolution files, up to PCM 32bit 768kHz, DSD512 and MQA. The USB input also uses a CPLD to process the clock signal and thus considerably reduce the jitter level.

Topping E50 DAC ES9068AS XMOS XU216 Symétrique MQA 32bit 768kHz DSD512

Full connectivity & Balanced output

Topping's DAC benefits from a complete connectivity to adapt to all types of audio systems. We can find USB-B, Optical Toslink and Coaxial as inputs. On the output side, the E50 offers both single-ended RCA and a double 6.35mm TRS jack for balanced output.

The TRS output does not support an adapter to convert the signal to single-ended and cannot be connected directly to headphones.

Topping E50 DAC ES9068AS XMOS XU216 Symétrique MQA 32bit 768kHz DSD512

Power supply & Auto ON/OFF

The Topping E50 is powered by 5VDC, either via its DC jack connector or directly on its USB-B input. It also benefits from an automatic on/off function. Thus, if the E50 receives a signal, it turns on automatically. In the same way, if it does not receive any signal on the selected input during 1 minute, then the E50 turns off.

Preamplifier function

The E50 has a preamplifier function. It is thus possible to control the volume level thanks to the remote control supplied. Ideal for association with a power amplifier or active speakers.

Technical characteristics

Specifications
Product typeDAC
DAC ChipESS ES9068AS
Supported sampling ratesUSB : PCM up to 32bit 768kHz, Native DSD up to DSD512, DSD DoP up to DSD256, MQA
Optical, Coaxial : PCM up to 24bit 192kHz, DSD DoP up to DSD64, MQA
Entrées1x USB-B
1x Optical Toslink
1x Coaxial
Outputs1x Single-ended stereo RCA
1x Balanced stereo Jack 6.35mm TRS
Measurements @ USB, 96kHz
THD+N @ A-WeightingSingle-ended: < 0.0001% @ 1kHz
Balanced : < 0.00009% @ 1kHz
THD @ No-Weighting 90kBwSingle-ended: < 0.0003% @ 20Hz-20kHz
Balanced : < 0.0003% @ 20Hz-20kHz
SNR @ A-WeightingSingle-ended : 124dB @ 1kHz
Balanced : 126dB @ 1kHz
Dynamic range @ A-WeightingSingle-ended : 124dB @ 1kHz
Balanced : 126dB @ 1kHz
Frequency responseSingle-ended : 20Hz-40kHz (±0.3dB)
Balanced : 20Hz-40kHz (±0.3dB)
Output levelSingle-ended : 2Vrms @ 0dBFS
Balanced : 4Vrms @ 0dBFS
Noise @ A-WeightingSingle-ended : < 1.3µVrms
Balanced : < 2.3µVrms
CrosstalkSingle-ended : -130dB @ 1kHz
Balanced : -139dB @ 1kHz
Output impedanceSingle-ended : 20Ω
Balanced : 100Ω
General
Supply voltage5VDC
Dimensions129 x 155 x 41mm
ColorBlack
Package1x Topping E50
1x Remote control
1x USB-A to Jack DC power cable
1x USB-A to USB-B cable
Topping E50 DAC ES9068AS XMOS XU216 Symétrique MQA 32bit 768kHz DSD512 Topping E50 DAC ES9068AS XMOS XU216 Symétrique MQA 32bit 768kHz DSD512 Topping E50 DAC ES9068AS XMOS XU216 Symétrique MQA 32bit 768kHz DSD512

Data sheet
InputOptical
InputSPDIF
InputUSB
OutputJack 6.35mm
OutputRCA
DAC / ADC ChipES9068AS
Max sampling rate768kHz
Max sampling rateDSD512
ColorBlack
NetworkingNo
Remote ControlYes
