TOPPING D50 DAC 2x ES9038Q2M 32bit/768kHz DSD512 XMOS U208 Silver

TOPPING D50 DAC ES9038Q2M x2 32bit/768kHz DSD512 XMOS U208 Silver
-11%

The DAC D50 combines all the know-how of Topping in an aluminium case with precise finishes. Its design and operation reflect and evolve a proven circuit architecture recognized for its efficiency.

Average votes for this product
5.0 / 5


Reduced price!
Reference : 12813
New product
Limited special offer

174,17 €

-11%

154,17 €tax excl.

Including 0,04 € for green tax
This product is no longer in stock
Produit garantie 2 ans

Accessories for this product


More info

Topping D50

32bit 768kHz 2x ES9038Q2M DAC Silver

Topping D50 DAC

The DAC D50 combines all the know-how of Topping in an aluminium case with precise finishes. Its design and operation reflect and evolve a proven circuit architecture recognized for its efficiency.

Incorporating advanced components, such as two ES9038Qm chips, a latest generation XMOS U208 module and OP1612 Operational Amplifiers, it is a qualitative material designed for excellence.

USB XMOS U208 and 2xES9038K2M - The winning duo


The D50 features some of the best components on the market for high quality rendering and an advanced audio experience. An XMOS U208 USB chip, a duo of ES9018K2M chipset operating in parallel so that all channels benefit from a detailed and accurately processed signal.

The DAC D50 has THESYCON drivers optimized for Windows offering native DSD support (from DSD64 to DSD512). It is therefore an obvious choice for music lovers in love with High Definition.

High Performances TI OPA1612 SoundPlus


The D50 features advanced sound processing with a trio of OPA1612 operational amplifiers. These allow the D50 to take advantage of a preamplifier function to maintain a clear, lossless signal.

Preamp feature

In addition to a very low distortion rate (0.0004%) and almost zero noise, these PDOs have a generous headroom. Audiophiles will appreciate this comfortable margin to find the optimal amplification level according to the specificities of their installation.


7 integrated PCM filters

If the DAC 50 is first native DSD512, the processing of PCM messages is not in rest since the device is able to work with resolutions up to 24bit/192kHz on its Coaxial and Optical inputs. Users can choose from 7 filter profiles to get the most out of their PCM encoded files. See the complete list of filters here.

Mobile stand and tablet

Whether via a Lightning port (with a Lightning > USB adapter) or directly with a USB-A / Micro-USB cable equipped for data (OTG), the D50 is equipped to function as a lossless drive to enjoy all the qualities of this DAC on all your digital sources.

Controlled ergonomics

Contrary to what its capabilities might suggest, the DAC 50 is a relatively easy to use device with a fairly intuitive grip. A single switch with a single button is sufficient to control all DAC50 functions (power on/off, volume, mute, source, auto standby, screen brightness and PCM filter activation).


Test Audio Science Review



The Topping D50 was the subject of a detailed comparative analysis by the Audio Science Review platform.

Click here to access the Topping Review.


Technical characteristics

Specifications
DAC2x ESS Sabre ES9038Q2M
Max sampling rate32bit 768kHz / DSD512 Native
THD< 0,0004% at 1kHz / < 0,0005% at 20Hz-20kHz
SNR> 122dB
Frequency response20Hz - 20kHz
Sampling rate per digital input
USB InputPCM 44.1kHz-384kHz 16-32bit
USB DSD ResolutionDSD64 à DSD512 (DOP - Natif)
SPDIF Coaxial input24bit max / 44.1kHz - 192kHz
Optical SPDIF input24bit max / 44.1kHz - 192kHz
USB CompatibilityWindows 7,8,8.1, 10 (requires a driver) / Mac OS 10 / Linux
General
Power supplyVia USB 5V port
Dimensions146 x 103 x 37mm
Weight407g
ColorSilver
Accessories1x USB cable
PCM filters
Mode 1Apodizing fast roll-off filter
Mode 2Minimum phase slow roll-off filter
Mode 3Minimum phase fast roll-off filter
Mode 4Linear phase slow roll-off filter
Mode 5Linear phase fast roll-off filter
Mode 6Brick wall filter
Mode 7Correction minimum phase fast roll-off filter
Package
1xD50
1xUSB-A / USB-B Cable
1xUSB / Jack DC Power cable (AC adapter available as accessory here).
1xuser manual
1xWarranty booklet

Data sheet
InputUSB XMOS
InputOptical
InputSPDIF
OutputRCA
DAC ChipES9028Q2M
Max sampling rateDSD512
Max sampling rate768kHz
ColorSilver
Components / ChipES9038Q2m
MaterialMetal
Channel2 channels (Stereo)
