Supravox 400 GMF PRO - 35 cm - 98 dB - 32 Hz / 4 kHz

This high-performance bass speaker (98.5 dB) is for the sound system.
Its exponential membrane ensures a wide bandwidth with a natural cut at 4000 Hz without accidents at the end of the band. Its 220 mm ferrite motor provides the necessary field to achieve such sensitivity.

These qualities allow it to be directly coupled with a 1 inch motor mounted on our roof.
Mounted in a bassreflex box, cut at 1200 Hz, with a filter at 18 dB / oct for the horn and 12 dB / oct for the 400, the response curve will be straight to ± 2 dB up to the final frequency of the motor 1 thumb.


Specifications:

Re
Sensitivity 1 W / 1m to Fs98 dBfs32 Hz
Impedance8 ohms6.5 ohms
Bandwidth32 to 4kHzqt0.26
Max power RMS120WQe0.27
Weight10.7 kgQm9.5
SuspensionCanvasVas370
Linear excursion10 mmbl18
Ferrite magnet220 mmcms
0.36
Magnetic field1.8 Tmms70 g
DIAMETe HP404 mmsd
855 cm²
Thickness salad bowlAlu 10mm
Distance fixing holes382 mm
Diameter drilling enclosure358 mm
HP Depth165 mmyl = "font-size: small;">

Near field frequency response:

https://www.audiophonics.fr/images2/7529/7529_400GMFPRO_1.jpg

Frequency response from 200 Hz to 20 kHz in the axis:

https://www.audiophonics.fr/images2/7529/7529_400GMFPRO_2.jpg

Frequency response from 200 Hz to 20 kHz at 30 °:

https://www.audiophonics.fr/images2/7529/7529_400GMFPRO_3.jpg

Frequency response from 200 Hz to 20 kHz at 60 °:

https://www.audiophonics.fr/images2/7529/7529_400GMFPRO_4.jpg

Impulse response:

"http://www.audiophonics.com/images2/7529/7529_400GMFPRO_5.jpg"

Waterfall

https://www.audiophonics.fr/images2/7529/7529_400GMFPRO_6.jpg

Impedance:

https://www.audiophonics.fr/images2/7529/7529_400GMFPRO_7.jpg

=> More information on the Supravox website


Data sheet
Speaker Power (W RMS)120.0
Speaker TypeWoofer
Impedance (Ω)8
Loudspeaker diameter (mm)350.0
Diaphragm typeN/A
Efficiency / Sensitivity (dB)98.0
Max Linear Excursion (Xmax) (mm)10.0
Lowest frequency (Hz)32
Highest frequency (Hz)4000
